AV Video Switcher Module Switch Unit 5-10V
SKU: 2553-RC
Manufacturer: RC

R 71.64
STOCK LEVEL: 5
Shipping Weight: 50g
Product Description
Features:
Two/Three channel electronic video switcher, which can control 2 (3) cameras or DV AV signals through the remote control.
Switch to the OSD or video transmitter separately to give your FPV a different angle of view.
Dedicated video switching IC, lossless picture quality, ultra-small internal resistance.
Can also be used as an electronic switch, electronic ignition, shutter trigger, air switching, transmitter channel, and etc.
Can be connected to any channel of the receiver to use (PWM), actually using two (three) gear switches or knob channels to use.

Note:
Please pay attention to the wiring sequence when using.
The video switching module itself is powered by the receiver 5V (also can be powered separately 5-10V).
Do not connect more than 10V to the video switching module.

Specificaion:
Item Name: AV Video Switcher Module
Input Power: 5V-10V
Input Control: 1-2MS PWM
Channel: 2CH, 3CH (optional)
Size: 16*16mm
Weight: 0.8g
Indicator:
Steady light
Fast flash
Slow flash

Package Included:
1x AV Video Switcher Module
2x Pin
